316SS SOLUTIONS
316 Stainless Steel
ACTUATORS
| CONSTRUCTION | SCOTCH YOKE | HEAVY DUTY |
| ACTION | SPRING RETURN | DOUBLE ACTING |
| MATERIAL | AISI 316 STAINLESS STEEL |
| VALVE APPLICATION |
ON-OFF | MODULATING | HIPPS QUARTER-TURN | LINEAR PNEUMATIC | HYDRAULIC |
| DESIGN | ISO 12490 | API 6DX | EN15714 | ASME VIII |
| TORQUE | QUARTER-TURN Nm 2.000.000 |
| THRUST | LINEAR N 10.000.000 |
| TEMPERATURE RANGE |
°C -29°/+100° (F°-20/+212°) °C -60° (F°-76°) on request |
| DESIGN PRESSURE |
PNEUMATIC Barg 12 HYDRAULIC Barg 250 (Barg 690 on request) |
| IP PROTECTION | IP66 | IP67M |
| ATEX | YES |
| EAC CU TR | YES |
| PED | YES |
| SIL CAPABILITIES |
3 |
PROCONTROL actuators portfolio includes quarter-turn and linear actuators in 316 stainless steel suitable for an extensive number of applications such as freezing and arctic environments, hot & humid marine environments, highly corrosive chemical environments and more. From an operation and production point of view, they lower considerably regular field maintenance costs.
316 Stainless Steel
GEAR BOXES
| MATERIAL | AISI 316 STAINLESS STEEL |
| VALVE APPLICATION |
ON-OFF |
| TORQUE | UP TO Nm 16.000 |
| STROKE RANGE | 0-90° (+/- 5° adjustable) |
| TEMPERATURE RANGE |
°C -29°/+100° (F°-20/+212°) °C -60° (F°-76°) on request |
| IP PROTECTION |
IP66 / IP67 / IP68 TUV tested and certified |
| PADLOCKABLE FLANGE | YES |
MAIN FEATURES
- Specifically engineered for offshore use
- Robust construction to meet the most challenging expectations, harsh weather protection
- Zero maintenance
- Self-locking movement
- Blind tapped threaded connection
- Absence of a cover plate
- Dome water run off position indicator
- Graduated Open & Close rotation scale
- Input shaft axial needle roller thrust bearings
- Aluminum bronze quadrant rotation bushings with O-ring sealing
- O-ring sealed position indicator;
- O-ring sealed lower modular mounting flange;
- IOGP S-562 / API6D 25TH ed. compliant;
- Stainless steel SS316 Grease injection nipples on gear housing and position indicator quadrant shaft void;
- Stainless steel SS316 housing overpressure relief valve;
- Limit switch box standard Namur drive slot located in the position indicator;
- Standard predrilled for limit switch mounting (assembly kit supplied if requested);
- Pad-lockable hand wheel.
- Fluorosilicone O-rings
PROCONTROL SGB Quarter-Turn 316 stainless steel gear operators have been created as a complementary product to our range of 316 stainless steel actuators: specifically engineered for long stand still operation in harsh and hostile conditions of all quarter turn valves such as ball, butterfly and plug valves.
